Genebre Art5540 3-Way L-Port Actuated Stainless Steel Ball Valve (PN40 Flanged)

Genebre Art5540 Stainless Steel Flanged 3-Way L-Port Ball Valve Fitted With a GNP Pneumatic Actuator

Actuated full bore 3-way stainless steel ball valve based on the Genebre Art2540

3-Way ball valve with an L-port ball configuration

Comes with PN40 flanged ends conforming to BS EN 1092-1:2018

Body made of shot blasted stainless steel 1.4408 (CF8M)

Ball made of stainless steel 1.4408 (CF8M)

Designed in accordance with the DIN 3357 & BS EN 12516-1 standards for industrial valves

Four ball seats, each made of PTFE & 15% graphite

Anti-static device enables use with flammable materials

Actuator mounted using the built-in ISO 5211 direct mount bracket

Blow-out proof stem made of stainless steel 316 with an FKM (Viton) O-ring

Maximum operating pressure: 40 bar (PN40)

Operating temperature range: -25°C – 180°C

Comes with a factory fitted Genebre Art5800 GNP pneumatic actuator

Rack and pinion operation with a 90° rotation (quarter turn)

Uses compressed air or any other inert gas for opening and closing the valve

Actuator feed connections: G1/4″ Threaded

Actuator feed pressure range: 2 – 8 bar

Actuator operating temperature range: -20°C – 80°C

VDI/VDE 3845 (NAMUR) mount for compatible control valves or positioners
