About this product
Albion Art380 Bronze Lift Check Valve
The Albion Art380 is a dependable lift-type check valve designed to prevent reverse flow in fluid systems. It features a bronze CC491K body with a brass CW617N bonnet, sealed with a TEADIT NA 1100 gasket for reliable leak resistance. This valve conforms to BS EN 12288 (formerly BS 5154), ensuring compatibility with traditional bronze valve installations.
Internally, the valve incorporates a brass CW617N disc with a PTFE seat for consistent, low-friction sealing. With BSPP parallel threaded ends to ISO 228/1 and a versatile design suitable for horizontal or vertical installation, the Art380 is ideal for commercial and industrial water systems.
Key Features:
- Bronze CC491K body with brass CW617N bonnet
- Brass CW617N disc with PTFE seat
- TEADIT NA 1100 body gasket for secure sealing
- Female BSPP parallel threaded ends to ISO 228/1
- Conforms to BS EN 12288 (formerly BS 5154)
- Pressure rating: 20 bar (3/8″ – 2″), 16 bar (2 1/2″ – 4″)
- Operating temperature range: -10°C to 180°C (170°C max for 2 1/2″ – 4″)
Suitable for backflow prevention in hot and cold water systems, process lines, and a range of HVAC applications.
Specification
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Brand | |
| Valve Type | Lift Check Valve |
| Connections | Female BSPP Parallel Threads – ISO 228-1, BS EN 10226-1 |
| Manufacturing Standard | Conforms to BS EN 12288 (Previously BS 5154) |
| Body Material | Bronze (CC491K) |
| Bonnet Material | Brass (CW617N) |
| Disc Material | PTFE |
| Body Gasket Material | TEADIT NA 1100 |
| Maximum Operating Pressure | 20 bar (3/8" – 2"), 16 bar (2 1/2" – 4") |
| Operating Temperature Range | -10°C – 180°C (3/8" – 2"), -10°C – 170°C (2 1/2" – 4") |
| Additional Information | Suitable for saturated steam. Threaded bonnet. |
| Certification Availability | 2.1 Letter of Conformity Only – Must be requested at time of order |
