Stainless Steel 316 Square Head Plug – BSP Threaded

Albion SHP Stainless Steel 316 Square Head Plug BSPT

The Albion SHP square head plug is cast from high quality AISI 316 (CF8M) stainless steel, offering excellent corrosion resistance and long-lasting performance in plumbing, industrial, and process pipework systems. Its square head allows for easy tightening with a spanner or wrench, providing a secure seal for pipe ends in compact or challenging installations.

Featuring male BSPT taper threads manufactured to ISO 7-1 (EN 10226-1) standards and conforming to ISO 4144:2003, this stainless steel plug is suitable for water, steam, and a wide range of industrial fluids. Maximum operating pressure is 20 bar (PN20) at up to 40°C, with an operating temperature range of -20°C to 220°C. A hex head version is also available in the same range for standard installations requiring a hexagonal wrench interface.

Key Features:

• Cast from corrosion-resistant AISI 316 (CF8M) stainless steel
• Male BSPT taper threaded ends to ISO 7-1 (EN 10226-1)
• Square head for easy spanner or wrench installation
• Manufactured in accordance with ISO 4144:2003
• Maximum operating pressure: 20 bar (PN20) at up to 40°C
• Operating temperature range: -20°C to 220°C
• Seals off pipe ends in plumbing, industrial, and process systems
