EcoCam Brass part A male camlock with female BSP threaded end.

EcoCam Type A Brass Male Camlock Coupling (Female BSP Threaded)

Brand: EcoCam
SKU: 90A-BR

£0.00 – £27.06 ex. VAT

About this product

EcoCam Type-A Brass Male Camlock x Female Threaded Adapter

Brass body

Male camlock

Female BSPP parallel threaded end

Straight through connection

Quick connect/disconnect fittings requiring no specialised tools

Manufactured to the A-A-59326D standard (previously MIL-C-27437)

Compatible with all other camlocks to the same standard

Designed for use with low-pressure liquids, powders & granules, not suitable for compressed air or gas

Maximum operating pressure: 10 bar (150 PSI)

Specification

Weight N/A
Dimensions N/A
Brand

Coupling Type

Cam & Groove (Camlock) – Type A
Connections

Male Camlock x Female BSPP Parallel Threaded (ISO 7-1, BS EN 10226-1)
Manufacturing Standard

A-A-59326D
Body Material

Brass
Maximum Operating Pressure

10 bar
Additional Information

Compatible with all other camlocks to the same standard.
Certification Availability

2.1 Letter of Conformity Only – Must be requested at time of order
