EQOair Aluminium Female Straight Adapter

Brand: EQOfluids
SKU: 82.035

£242.40£688.00 ex. VAT

About this product

EQOair Aluminium PN16 Flange Adaptor

Push fit pipe fitting for use with compressed air

Body made of aluminium alloy to EN AW 6061 T6 (ENAB 42000)

RAL 5012 colour coded exterior marker

Comes with NBR seals

Clamp/grab rings in stainless steel 304

For use with PN16 flanges to BS EN 1092-1

Maximum operating pressure: 16 bar (PN16)

Flange diameter: See datasheet

Pitch circle diameter (PCD): See datasheet

Bolt holes: See datasheet

Operating temperature range: -30°C – 120°C

10 Year guarantee provided by EQOfluids

Specification

Weight N/A
Dimensions N/A
Brand

Fitting Type

PN16 Flange Adapter

Connections

Push Fit x PN16 Flanged (BS EN 1092-1:2018)

Body Material

Aluminium Alloy – EN AW-6061 (ENAB 42000)

Clamp Ring Material

Stainless Steel 304

O-Ring Material

NBR

Flange Outer Diameter

See datasheet

Flange PCD

See datasheet

Flange Thickness

See datasheet

Flange Bolt Holes

See datasheet

Maximum Operating Pressure

16 bar

Operating Temperature Range

-30°C – 120°C

Additional Information

RAL5012 Colour coded exterior marker. 10-Year manufacturers guarantee.

Certification Availability

N/A
